Product Overview
Wattgate 330i Clear Audio Grade Power Plug 15 Amp
Wattgate quality Audio Grade(R) Male plug with a clear body. 3 layer gold plating process. Cryogenically treated
A fast and easy way to make a big improvement in your home theater or audio system. The WattGate 330i is designed for quick and installation and excellent performance. The Wattgate 330i is constructed of high-quality materials such as an polycarbonate rear housing, available in either black or clear, and a durable nylon front housing. The 330i is engineered to be adaptable to a wide range of power cables, and the removable insert can accommodate cable diameters from 0.300" (7.62mm) to 0.655" (16.63mm).
Installation has been simplified with color coded, tightly spaced, funnel shaped holes to guide the conductors into the unique Perma-Lock™ terminals. Perma-Lock™ terminals work in the following way: As the terminal screw tightens down on the contact tang, it compresses the wire underneath the tang, the screw exerts an upward lift of the collar overleaf. This lifting action "locks up" the threads screws. Stress on the terminals is virtually eliminated. Heat cycling and vibration cannot loosen the screw.
The real secret behind the 330i lies with the contact elements themselves. Super thick contact tangs are used along with a three-layer plating process: Oxygen free copper plating, electrolysis nickel, and finally 24k gold plating dramatically improves conductivity and prevents corrosion. All Wattgate plugs are now cryogenically treated. the 330i is rated at 125 VAC, 15A, and accepts up to 10 gauge wire.
WG330i-CLR
