Product Description
Belden 19364 14 AWG 3 conductor Power Cable with drain wire Type SJT
Made in USA. RoHS Compliant
Pricing is PER FOOT
Belden 19364 is a UL Rated 3 wire stranded (41x30) cable with a Beldfoil® shield. Very flexible and easy to work with. We suggest the Schurter 4781 IEC as a good plug to use with this cable. We stock them.
Great for building your own audio and video power cables. Excellent replacement for small and mid-power amplifiers for home audio and theater, and for musical instrument amps.
If you are making a cable for your flat screen TV or Video, we recommend using a silver plated IEC plug if possible. They work great at video frequencies.
This cable will work fine with Marinco, Oyaide, Furutech, and Wattgate plugs and IEC's as well.
FEP insulation, conductors cabled, 100% Beldfoil® shield, PVC jacket. Stranding: 41x30 Conductor Material: BC - Bare Copper Insulation Material: PVC - Polyvinyl Chloride Outer Shield Material Trade Name: Beldfoil® Outer Shield Material: Aluminum Foil-Polyester Tape Outer Jacket Material: PVC - Polyvinyl Chloride. Not Plenum rated.
| Cable Type | : | Portable Cord |
| Color Code | : | Light Blue, Brown, Green⁄Yellow |
| Color, Jacket | : | Black |
| Cordage Type | : | SJT |
| Diameter, Outer | : | 0.402 in. |
| Length | : | 250 ft. |
| Material, Conductor | : | Bare Copper (BC) |
| Material, Insulation | : | Polyvinyl Chloride (PVC) |
| Material, Jacket | : | Polyvinyl Chloride (PVC) |
| Material, Shield | : | Aluminum/Polyester Tape |
| Number of Conductors | : | 3 |
| Packaging | : | Coil |
| Product Header | : | Portable Cordage |
| Series | : | 19364 |
| Shielding | : | Foil |
| Standards | : | NEC SJT, CSA SJT |
| Stranding | : | 41x30 |
| Temperature, Operating | : | 60 °C |
| Temperature, Rating | : | 60 C |
| Thickness, Insulation | : | 0.033 in. (Nom.) |
| Voltage Rating | : | 300 V |
| Wire Size | : | 14 AWG |
